Semi-Automatic Powder Filling Machine (CCL-10L)
The CCL-10L semi-automatic powder filling machine is a compact, servo-driven auger dosing system engineered for accurate, repeatable filling of powders and fine granules into bags, jars, cans, and other containers. Built on PLC control with a responsive 7-inch touchscreen, it enables fast recipe setup, stable operation, and straightforward daily use in production environments that demand consistent fill quality and flexible batch handling. The machine integrates screw metering, anti-bridging agitation, and a hygienic 304 stainless-steel structure to support clean operation and minimized material residue. With practical workshop-oriented details—such as an independent electrical cabinet, filling platform, foot-pedal discharge control, mobility wheels, and adjustable leveling feet—the CCL-10L is an ideal solution for manufacturers seeking dependable semi-automatic performance while maintaining easy access for cleaning and routine maintenance.
Product Features
Servo-Driven Auger Metering for Consistent Accuracy
A high-performance servo motor drives the dosing screw, allowing precise control of speed and torque for stable output. This auger-based approach delivers repeatable fill results across a wide range of powder behaviors, helping reduce underfill/overfill risk and supporting both smaller batches and continuous workshop production.
PLC Control + Touchscreen HMI for Fast Setup
The PLC program and 7-inch touchscreen provide intuitive operation with clear parameter setting and quick adjustment during changeovers. A bilingual Chinese/English interface, alarm prompts, and self-diagnosis functions improve usability, shorten operator training time, and help troubleshoot issues promptly to reduce downtime.
Anti-Bridging Stirring for Smoother Feeding
An integrated stirring motor promotes steady material flow inside the hopper, reducing bridging, channeling, or powder adhesion to the hopper wall. This improves auger feeding consistency, supports more stable dosing, and helps keep production running smoothly when handling powders with moderate cohesion.
304 Stainless-Steel Construction for Hygiene and Durability
The welded frame and machine body are manufactured from 304 stainless steel to enhance corrosion resistance and sanitation. A vertical short-screw design with laser full welding creates a seamless, cleanable structure that helps minimize residue retention and simplifies routine cleaning between batches.
Safety Interlocking and Clear Process Visibility
A hopper door detection switch prevents operation when the material door is not properly closed, improving operator safety and reducing the chance of unintended discharge. An acrylic viewing window supports easy observation of material level, enabling timely refilling and more consistent process control.
Workshop-Friendly Integration and Maintenance
An independent electrical cabinet improves wiring organization and service convenience. A filling platform supports stable container placement, while a foot-operated discharge switch enables hands-free operation for better efficiency. Universal wheels and adjustable feet (up to +50 mm) make it easier to position, move, and level the unit on different factory floors.
Technical Specifications
| Model | CCL-10L |
| Machine Type | Semi-automatic powder filling machine / servo auger dosing filler |
| Measuring Range | 400–2000 g (includes one auger set for 400–500 g) |
| Filling Accuracy | ±1–2% |
| Filling Speed | 15–40 bags/min (material- and target-weight dependent) |
| Total Power | 2370 W (including 2000 W Inovance servo motor) |
| Power Supply | 380 V, 50 Hz, three-phase |
| Hopper Capacity Options | 50 L / 100 L / 200 L |
| Control System | PLC + 7-inch touchscreen (Chinese/English), alarm & self-diagnosis |
| Electrical Components | Schneider or OMRON |
| Material of Construction | 304 stainless steel (welded frame and body) |
| Mobility & Leveling | Universal wheels + adjustable feet (+50 mm) |
| Included Functional Parts | Independent electrical cabinet, filling platform, foot-operated discharge switch, acrylic viewing window |
| Safety / Interlock | Hopper door detection switch (prevents operation when door is not properly closed) |
| Optional / Recommended Protection | Stainless-steel dust covers for servo motor and stirring motor |
Application Fields
Food & Ingredients
Designed for powder filling tasks such as flour, milk powder, coffee powder, cocoa, seasoning mixes, protein powders, and similar products where stable dosing, cleanable structure, and reliable operation are essential.
Pharmaceutical & Health Products
Suitable for nutritional powders, supplement premixes, and related formulations requiring controlled, repeatable filling, user guidance via HMI, and fast fault identification through diagnostic alarms.
Chemicals & Industrial Powders
Applicable to pigments, additives, resin powders, detergent powders, and other industrial materials that benefit from servo-controlled auger metering, anti-bridging agitation, and durable stainless-steel construction.
Agriculture & Feed Additives
Used for premixes, vitamin/mineral additives, and similar powdered products, offering efficient semi-automatic filling with hopper capacity options to match different batch sizes and production rhythms.
