The Fully Automatic Filling Production Line is a modular, high-efficiency solution for can and jar packaging of powders, granules, liquids, tablets, capsules, and pills. Built around a continuous workflow—container infeed and orienting, optional sachet insertion, material lifting, weighing/dosing, online checkweighing with reject, induction sealing, capping, labeling, and coding—this line supports stable operation from 20 to 80 cans per minute (depending on product flowability, dosing method, and target weight). Designed for fast integration and simplified commissioning, it helps manufacturers transition from semi-automatic handling to a standardized, traceable, and scalable automated packaging process.
Product Introduction
This production line integrates multiple packaging functions into one coordinated system for retail-ready and compliance-oriented can/jar filling. Each station is engineered as an independent module (rotary table, elevator, weigher/filler, checkweigher, sealer, capper, labeler, coder), allowing the final configuration to match your container size, material characteristics, and output goals. From upstream material conditioning to downstream marking, the line focuses on fill accuracy, process stability, and quality verification—delivering consistent results while reducing operator dependence.
Product Features
Multi-Format Capability for Diverse Products
The line supports powders, granules, liquids, and solid-dose formats such as tablets, capsules, and pills. By selecting the appropriate feeding and metering modules, the same line architecture can be adapted for different SKUs, helping you expand product ranges without duplicating equipment or reorganizing the workshop layout.
Flexible Throughput for Real Production Conditions
With a practical output range of 20–80 cans/min, the system can be tuned for pilot batches, seasonal demand, or high-volume production. Speed is evaluated according to product behavior and dosing approach, enabling a balanced setup between throughput, dosing stability, and accuracy for each application.
End-to-End Automation to Reduce Labor and Human Error
Operators load materials into the elevator hopper while empty containers are automatically sorted and conveyed. Optional desiccant/deoxidizer sachets can be inserted on signal. Product is then weighed and dispensed, unqualified items are automatically rejected, and qualified containers proceed to sealing/capping, labeling, and coding before final manual case packing. Interlocked controls and station-to-station logic reduce missed steps and improve overall operational discipline.
100% Online Weight Inspection with Reject Handling
An inline checkweigher performs continuous weight verification for every filled container, automatically removing underweight or overweight products. This replaces manual sampling with full-process inspection, strengthening compliance, improving customer satisfaction, and protecting brand reputation—particularly valuable for regulated industries and premium retail channels.
Cleaner, More Stable Feeding with Screening and Iron Removal
The Z-type bucket elevator integrates a vibration groove and filtering structure to separate dust and sediment into a collection tray. An iron removal rod captures ferrous contaminants during material transfer. These protective measures improve weighing consistency and reduce the risk of foreign matter entering the finished product.
Retail-Ready Sealing, Capping, Labeling, and Coding
A continuous aluminum foil induction sealer (air-cooled) delivers strong, leak-resistant seals for shelf-life protection, while the servo-driven capping unit ensures controlled tightening torque. A servo labeling machine provides consistent placement on round or irregular containers and supports code integration for dates, batch numbers, barcodes, and QR codes—helping you achieve traceability and clean shelf presentation.
Modular Design for Faster Installation and Future Expansion
Because each function is built as a dedicated module, the line can be customized to your container format, target output, and product properties. Packaging details and final line dimensions are configured to your specifications, supporting efficient installation today and straightforward upgrades tomorrow.
Technical Specifications
Line Overview
| Line Type | Fully automatic can filling, sealing/capping, labeling & coding production line |
| Applicable Filling Materials | Powder, granules, liquid, tablets, capsules, pills |
| Line Speed | 20–80 cans/min (based on product and measurement method) |
| Minimum Order Quantity | 1 production line |
| Packaging Details | Customized according to product specifications |
| Delivery Time | 45 work days |
| Payment Terms | T/T |
LP-1200 Tank Inlet Rotary Table (304 Stainless Steel)
| Application | Automatic feeding and arranging of round cans/bottles |
| Rotary Table Diameter | Φ1000 mm |
| Capacity | ≤ 60 cans/min |
| Conveyor Height | 850 mm (from floor to belt) |
| Power | AC 220 V / 50 Hz, 400 W |
| Weight | 80 kg |
| Dimensions | 1100 × 1100 × 1050 mm |
TB-P-30 Desiccant/Deoxidizer Feeding Machine (Three-Side Seal)
| Function | Automatically cuts and drops one desiccant/deoxidizer sachet into each container on signal |
| Control | PLC with color mark tracking |
| Capacity | ≤ 100 bags/min |
| Max Sachet Size | 80 (W) × 130 (L) × 30 (H) mm |
| Max Roll Diameter | ≤ 300 mm |
| Cutting Method | Flat cut |
| Gas Consumption | 6 kg, 0.2 m³/min |
| Power | AC 220 V / 50 Hz, 400 W |
CST-1.8L-2400 Z-Type Bucket Elevator
| Application | Lifting small particles, flakes, blocks to the weighing/filling module with automatic feeding |
| Capacity | ≤ 5 m³/h |
| Contaminant Handling | Dust/sediment screening + iron removal |
| Chain Material | 304 stainless steel |
| Bucket | PP, 1.8 L full volume |
| Storage Hopper | 60 L |
| Power | AC 220 V / 50 Hz, 900 W |
ZXGZ-MHW10-1.6L Linear Weighing & Filling Machine (with Reject + Extended Conveyor)
| Function | Automatic weighing, dosing, and container filling with unqualified collection |
| Weighing Buckets | 10 buckets; 256 weight combinations |
| Weighing Speed | ≤ 60 times/min |
| Weighing Range | 10–500 g (no accessory replacement required) |
| Max Material Length | 80 mm |
| Accuracy Level | X0.5 level |
| Functions | Container positioning + bottom vibration; automatic reject and collection |
| Gas Consumption | 6 kg, 0.2 m³/min |
| Power | AC 220 V / 50 Hz, 1000 W |
CW-2140 Online Weight Sorting Scale (with Reject)
Single Weighing Range</td
