JW-AM14 14-Head Salad Multi-Head Weigher (5000 ml, up to 70 bags/min)
The JW-AM14 is a high-capacity 14-head multi-head weigher designed for fast, consistent portioning of bulky, large-piece, and large-granule products. Built around a 5000 ml hopper volume and a wide dosing range of 100–5000 g, it supports packaging lines that handle higher target weights and variable flow behavior—such as mixed salads, leafy greens, cut vegetables, fruits, beans, nuts, and similar items. By combining stable product distribution, repeatable actuation, and an intuitive 7-inch touch-screen HMI, the JW-AM14 helps manufacturers maintain throughput and accuracy while reducing operator dependency and changeover time. It is well-suited for integration with vertical form-fill-seal machines, baggers, pouch lines, tray filling systems, and other downstream equipment where reliable combination weighing is required for continuous production.
Product Features
Engineered for voluminous and bulky products: With a 5000 ml hopper volume, the JW-AM14 accommodates items that are light yet space-filling (e.g., salad mixes) as well as products requiring higher dose weights, helping stabilize feeding and reduce interruptions caused by bridging or inconsistent flow.
High output with selectable performance priorities: Operators can choose operating modes that emphasize speed or tighter tolerance depending on product type, bag format, and allowable giveaway—supporting a practical balance between productivity and cost control.
Stable feeding via adjustable linear feeders: Each linear feeder supports amplitude adjustment in auto or manual mode, enabling fine control of product flow. This improves consistency across different textures and piece sizes, supporting reliable combinations and smoother discharge.
Configurable top-cone distribution: Optional rotary or vibration top-cone solutions help distribute product evenly to each weighing head, improving dispersion, reducing build-up, and strengthening overall weighing stability—especially important for irregular shapes and mixed components.
Operator-friendly multilingual touch-screen control: The 7-inch HMI provides clear parameter access, recipe management, and quick adjustments. Multilingual support simplifies training for global operations and helps standardize daily production routines.
Expandable handling components: Optional accessories such as a dimple plate and stopper ring can be added to enhance product movement, reduce sticking, and maintain consistent feeding behavior—useful for moist, leafy, or irregular products.
Reliable step-motor drive system: The step motor drive delivers repeatable motion control and stable actuation, supporting consistent cycle performance during long production runs and frequent start-stop operation.
Technical Specifications
| Model | JW-AM14-1-1 |
| Weighing Range | 100–5000 g |
| Weighing Accuracy | ±3–10 g |
| Maximum Speed | 10–70 bags/min |
| Hopper Volume | 5000 ml |
| Control Panel | 7" Touch Screen |
| Available Options | Dimple Plate; Rotary Top Cone; Stopper Ring |
| Drive System | Step Motor |
| Power Supply | 220V / 2000W / 50/60Hz / 12A |
| Machine Dimensions (L × W × H) | 2179 mm × 1382 mm × 1805 mm |
| Gross Weight | 650 kg |
Note: Specifications are provided for reference. Actual speed and accuracy depend on product characteristics, target weight, feeding conditions, and packaging configuration.
Application Areas
The JW-AM14 is recommended for weighing and portioning applications where products are bulky, irregular, or require higher target weights per dose, including:
Fresh and prepared foods: mixed salads, leafy vegetables, cut vegetables, fruit portions, ready-to-eat fresh mixes, and other high-volume ingredients requiring gentle, consistent dosing.
Agricultural and dry goods: beans, nuts, dried fruits, large-granule ingredients, and mixed snack components where stable flow and repeatable combination weighing improve yield control.
Food processing and packaging lines: integration with bag, pouch, or tray packing systems and downstream fillers where throughput up to 70 bags/min and consistent portion control are critical for efficiency, quality, and reduced giveaway.
