JULONG’s Horizontal Automatic Pouch Filling and Sealing Machine is a compact, high-throughput packaging system engineered to produce clean, consistent pouches for granules, powders, and selected liquids using composite packaging films. By combining film feeding, pouch forming, metered filling, horizontal heat sealing, and precise pattern cutting into one continuous process, it streamlines production, reduces operator dependency, and helps manufacturers maintain stable output quality while saving valuable floor space. Built on servo-controlled film pulling and a repeatable pneumatic sealing structure, the machine is designed for dependable daily operation across multi-product packaging tasks where appearance, seal integrity, and dimensional consistency are essential.
Product Introduction
Designed for modern pouch-pack applications, this horizontal form-fill-seal solution adopts a roller-type bag pulling mechanism driven by a Schneider servo motor. The servo system enables steady film transport and accurate pouch length control, supporting consistent sealing alignment during continuous running. A “Yadeke” cylinder-based horizontal sealing assembly delivers stable pressure and repeatability, producing a straight, uniform seal with a 10 mm sealing width for improved strength and visual presentation. Pattern cutting with defined spacing ensures standardized pouch separation and tidy edges, reducing trimming defects and improving downstream cartoning, counting, and packing efficiency. The forming section supports a forming width up to 320 mm and is supplied with a flip-collar forming set, allowing flexible adaptation to different pouch formats and production requirements.
Product Features
Servo-driven film pulling for stable pouch length and rhythm. The Schneider servo motor and roller pulling system provide smooth, repeatable film transport, helping reduce film jitter and maintaining consistent registration and bag length across long production runs.
Reliable pneumatic horizontal sealing for strong, clean seals. The “Yadeke” cylinder horizontal sealing structure supports consistent sealing pressure and repeatability. The straight seal pattern combined with a 10 mm sealing width enhances seal strength and improves finished-pack appearance.
Precision pattern cutting for neat edges and standardized separation. Pattern cutting with 3 mm spacing produces uniform pouch edges and consistent cut quality, improving shelf presentation and reducing issues such as irregular tearing, burrs, or misaligned separation.
Flexible forming capability for multiple pouch specifications. With a forming width up to 320 mm and a flip-collar forming set included, the machine accommodates a broad range of pouch sizes and adjustments, supporting quick changeovers for different SKUs and packaging requirements.
Optimized for composite packaging films. Compatible with common composite materials used for barrier performance and shelf-life protection, the machine meets typical packaging needs in food, chemical, and daily-use product segments.
Practical filling accuracy aligned with material and dosage. Measurement accuracy is rated at ±1–10% depending on packaging material properties and fill quantity, supporting real-world production conditions for powders, granules, and applicable liquids.
Efficient compressed-air usage. Gas consumption of 0.2 m³/min balances stable pneumatic actuation with cost-aware operation in air-supplied factory environments.
Liquid-friendly sealing detail (when applicable). For liquid applications within the supported range, a 1 mm horizontal sealing leak-proof line helps improve sealing integrity and reduce leakage risk (applicable to liquid packaging only).
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Horizontal Automatic Pouch Filling and Sealing Machine |
| Bag Pulling Method (Roller System) | Roller Bag Pulling (Schneider Servo Motor) |
| Bag Pulling Method (Drive) | Servo Motor Drive, Hot Sealing and Film Pulling |
| Cutting Method | Pattern Cutting (Spacing of 3 mm) |
| Horizontal Sealing Method | “Yadeke” Cylinder Horizontal Sealing |
| Horizontal Sealing Pattern | Straight Pattern (Spacing of 2 mm), Sealing Width: 10 mm |
| Forming Machine Width | ≤ 320 mm (Supplied with 1 set of flip-collar forming set) |
| Packaging Film | Composite Packaging Material |
| Gas Consumption | 0.2 m³/min |
| Measurement Accuracy | ± 1–10% (Depending on packaging materials and quantity) |
| Packaging Capacity | 50–500 ml |
| Horizontal Sealing Leak-Proof Line | 1 mm (Applicable to liquid packaging only) |
| Machine Weight | 350 kg |
Application Fields
Built for automated pouch packaging lines that require consistent forming, accurate filling, stable sealing, and clean cutting, this machine is suited to a wide range of pack-ready products compatible with composite films.
Food & beverage: granules and powders such as sugar, salt, flour, coffee mixes, seasoning blends, drink additives, and other free-flowing materials; selected liquid products within the supported filling range.
Chemicals & daily-use products: detergents, cleaning powders, granular additives, desiccants, and other industrial or household materials requiring standardized pouches and dependable seals.
Pharmaceutical & health-related packaging: non-sterile powders and granules where consistent pouch dimensions, stable sealing, and clean cutting are required, subject to the compliance standards and validation procedures of the user’s facility.
