Product Introduction
The Fully Automatic Strip Back Sealing Packaging Machine is a PLC-controlled, high-efficiency VFFS solution engineered for continuous strip packaging with stable back sealing. Designed to run reliably in modern factories, it integrates precision film handling, consistent heat sealing, and convenient operation through a responsive touch screen HMI. The machine is built with a hygienic 304 stainless-steel frame for durability and easy wash-down, making it a dependable choice for food, pharmaceutical, chemical, and daily-use product lines.
With a compact industrial footprint and a servo-driven bag pulling system, it delivers smooth film feeding, accurate bag length control, and uniform package appearance across different formats. The system supports multiple product forms—including powders, granules/particles, and liquids—helping manufacturers reduce manual intervention, improve throughput stability, and maintain repeatable packaging quality shift after shift. Whether used as a standalone packer or integrated into an automated line, it provides the performance and consistency needed to meet demanding production targets.
Product Features
PLC + touch screen control for simple, repeatable operation. The PLC architecture ensures stable machine logic and reliable running performance. The touch screen interface enables intuitive parameter setting, recipe storage, fast format changeover, alarm viewing, and daily operation, reducing training time and minimizing human error.
Servo motor heat-sealing bag pulling for precise film transport. The Siemens servo-driven pulling system delivers accurate film feeding and consistent bag length, helping reduce film deviation and improving registration stability. This supports steady output and consistent presentation, particularly important for branded packaging and retail-ready packs.
High-integrity sealing for professional package finish. The twisted edge vertical sealing form improves seal strength and helps maintain tight, clean back seals. The diagonal straight horizontal sealing form creates a neat top/bottom seal line, contributing to a premium appearance and helping protect product integrity during handling, storage, and transport.
Flexible cutting options to match market and product needs. Flat cut and serrated cut modes are available, allowing producers to choose separation style based on pack positioning, consumer preference, and downstream cartoning or bundling requirements.
304 stainless steel construction for hygiene and longevity. The corrosion-resistant stainless-steel structure supports long-term use in demanding environments and simplifies routine cleaning. This makes the machine suitable for applications where sanitation, contamination control, and equipment durability are essential.
Wide process compatibility for multiple product types. Designed to package powders, granules/particles, and liquids, the system adapts well to diverse production demands. It supports consistent bag forming and sealing quality across different product characteristics, helping maintain stable output and uniform finished-pack appearance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Fully Automatic Strip Back Sealing Packaging Machine |
| Machine Type | Packaging Machine |
| Packaging Product Type | Powder, Particles, Liquids |
| Control System | PLC |
| Display | Touch Screen |
| Voltage | 220V |
| Power | 2.2 kW |
| Speed | 20–50 bags/min |
| Film Thickness | 0.04–0.08 mm |
| Bag Size Range | Length 50–200 mm; Width 25–150 mm |
| Bag Pulling Method | Servo Motor Heat Sealing Bag Pulling (Siemens) |
| Vertical Sealing Form | Twisted Edge Sealing |
| Horizontal Sealing Form | Diagonal Straight Seal |
| Cutting Method | Flat Cut / Serrated Cut |
| Temperature Range | 0–300℃ |
| Machine Dimensions (L×W×H) | 1500 × 1000 × 2200 mm |
| Net Weight | 500 kg |
| Minimum Order Quantity | 1 |
| Delivery Time | 45 work days |
Application Fields
The Fully Automatic Strip Back Sealing Packaging Machine is designed for industries that require dependable sealing, consistent bag forming, and efficient automated throughput. In food and beverage production, it is ideal for sachets and small packs such as seasonings, sugar, coffee, instant drink powders, powdered mixes, and liquid concentrates where neat sealing and stable packaging speed are critical.
For pharmaceutical and health product manufacturers, the cleanable stainless-steel structure and reliable sealing performance support the packaging of granules, powders, and liquid doses where hygiene and package integrity are essential. It is also well suited to chemical and daily-use products—including detergents, additives, and fine particles—helping producers maintain uniform packaging quality and dependable cutting/sealing performance that protects products during distribution and storage.
