JW-AM10 10-Head Salad Weigher (Up to 50 PPM) — High-Accuracy Multihead Weighing Scale
The JW-AM10 is a 10-head multihead weigher purpose-built for fast, stable, and precise portioning of bulky, large-piece, and high-volume products—especially salad mixes, leafy greens, vegetable blends, and cut fruit. With a generous 5000 ml hopper volume and an output capability of up to 50 packs per minute (PPM), it supports continuous production while helping maintain consistent target weights and reduce product giveaway. The system combines gentle product handling with dependable metering, making it well-suited for fresh and ready-to-eat operations where hygiene, repeatability, and quick changeovers are essential. A 7-inch touch-screen HMI simplifies daily operation, recipe management, and real-time monitoring, enabling operators to keep performance steady across shifts and product variations.
Product Features
Large-volume hopper design for bulky products: The 5000 ml hopper capacity is optimized for lightweight, voluminous items and mixed compositions (e.g., salad blends), helping maintain a steady feed and minimizing bridging or irregular flow.
Reliable accuracy at production speed: Designed to achieve ±5–10 g accuracy while reaching up to 50 PPM, the JW-AM10 balances precision and throughput to improve weight consistency and control overfill cost.
Independent feeder amplitude control: Each linear feeder supports auto/manual amplitude adjustment, allowing fine tuning to match product characteristics (leafy, wet, irregular pieces). This improves dispersion, stabilizes weighing cycles, and enhances repeatability.
Configurable top distribution for better material handling: Rotary top cone and vibration top cone options help optimize product distribution to the weigh heads, improving flow uniformity and reducing the risk of product build-up.
Hygienic, washdown-friendly construction: IP65-rated waterproof and dustproof protection supports frequent cleaning—an important advantage for fresh produce and salad processing environments where sanitation is a daily requirement.
Operator-centric control experience: The 7” touch screen provides intuitive parameter setting, recipe storage, and production monitoring. Multi-language support simplifies training and enables consistent operation across international teams.
Expandable options for line integration: Optional accessories such as a dimple plate, timing hopper, printer, and rotary top cone allow the JW-AM10 to be configured for specific product behavior and packaging line requirements.
Technical Specifications
| Model | JW-AM10-1-1 |
| Max. Single Dump Capacity | 100–3000 g |
| Weighing Accuracy | ±5–10 g |
| Max. Weighing Speed | Up to 50 PPM |
| Hopper Volume | 5000 ml |
| Control Panel | 7” Touch Screen |
| Optional Configurations | Dimple Plate / Timing Hopper / Printer / Rotary Top Cone |
| Driving System | Step Rotor |
| Power Requirements | 220 V / 2000 W / 50–60 Hz / 12 A |
| Packing Dimensions (L×W×H) | 2179 × 1382 × 1805 mm |
| Gross Weight | 650 kg |
Application Areas
Fresh-cut and ready-to-eat foods: Salad mixes, leafy greens, mixed vegetables, fruit bowls, and assorted produce portions where gentle conveying and stable combination weighing are required.
Fresh produce processing: Chunky or large-granule materials that benefit from controlled feeding and consistent distribution across multiple weigh heads for uniform pack weights.
Automated packaging lines: Ideal for integration with VFFS baggers, premade bag packing systems, tray filling solutions, and downstream coding/printing and labeling equipment—supporting a smoother line flow and repeatable weight performance.
