Built for high-efficiency snus and nicotine pouch packaging, this 4-lane pouch filling machine combines precise dosing with ultrasonic sealing to deliver fast, clean, and repeatable results. Designed for laminated, heat-sealable pouch materials, it supports demanding production environments where throughput, hygiene, and sealing integrity directly impact product quality and brand presentation. Its compact industrial layout helps optimize floor space while maintaining stable, continuous operation for modern packaging lines.
Product Introduction
This equipment adopts a multi-lane parallel processing structure to complete pouch forming/feeding, filling, and sealing in a synchronized cycle, significantly improving output while keeping each lane consistent. Ultrasonic sealing technology provides reliable closures without excessive heat exposure, helping protect pouch material structure and maintaining a neat, uniform seal appearance. The machine is engineered for dry powder filling applications typical of snus pouch production, with a design emphasis on stable rhythm, minimized stoppages, and easy integration into existing factory utilities.
The control platform is based on PLC automation with a touch-screen HMI, enabling straightforward operation, quick parameter setting, and real-time status monitoring. Operators can switch between pouch sizes within the supported range with efficient adjustment, supporting both continuous high-volume manufacturing and flexible batch production. With robust mechanical construction and standardized pneumatic requirements, the system is a dependable core unit for scaling output while maintaining consistent packaging quality.
Product Features
Ultrasonic Sealing for Consistent, Clean Seams
Ultrasonic sealing delivers strong, uniform seals with excellent repeatability, helping reduce common packaging risks such as edge weakness, seal contamination, and micro-leakage. The process supports laminated pouch materials and produces a tidy finish that enhances shelf appearance and helps preserve product freshness.
4-Lane Parallel Operation for High Throughput
By running four lanes simultaneously, the machine increases production capacity without compromising process control. With speeds up to 180 pouches per minute, it is well-suited for manufacturers aiming to raise output while keeping sealing quality and pouch consistency stable across long production runs.
PLC + Touch Screen Control for Efficient Operation
The PLC-driven architecture and touch-screen interface simplify daily operation and reduce training time. Operators can quickly adjust settings, manage recipes, and monitor key running conditions, supporting steady performance, faster changeovers, and improved process visibility.
Industrial Stability with Energy-Conscious Performance
With a rated power consumption of 5.5 kW, the system balances productivity with operating cost. The rigid machine frame and durable components support continuous-duty production, while the 0.6–0.8 MPa air supply range aligns with common factory pneumatic standards for convenient line integration.
Practical Pouch Size Flexibility
Compatible with snus pouch sizes from 40–120 mm in length and 20–60 mm in width, the machine supports multiple formats on one platform. This flexibility helps brands and contract packers handle multi-SKU production, improve equipment utilization, and respond faster to market-driven format adjustments.
Technical Specification Parameters
| Product Type | Pouch Filling Machine |
| Sealing Type | Ultrasonic Sealing |
| Packing Speed | Up to 180 pouches/min |
| Number of Lanes | 4 |
| Control System | PLC control with touch-screen interface |
| Pouch Size Range | Length: 40–120 mm; Width: 20–60 mm |
| Air Pressure | 0.6–0.8 MPa |
| Power Consumption | 5.5 kW |
| Machine Dimensions (L × W × H) | 2200 × 1200 × 1800 mm |
| Pouch Type | Snus pouch |
| Filling Material | Dry powder |
Product Application Fields
This 4-lane ultrasonic sealing snus pouch packing system is widely applied in snus and nicotine pouch manufacturing lines that require high output, stable automation, and consistent sealing quality. It is an ideal solution for tobacco-related production facilities and packaging plants seeking reliable performance, controlled sealing results, and improved labor efficiency through streamlined automation.
Typical use cases include high-volume snus pouch production, contract packaging services, and factories expanding capacity while maintaining consistent pouch appearance and seal integrity. With its supported size range and user-friendly controls, the machine also performs effectively in multi-SKU environments where frequent format changeovers and repeatable packaging results are essential.
